Figure 4-39
Horizontal Situation Indicator
Page 4-22
091-00027-001 Rev A EBD Pilots Guide V&H .indb 22
4.4. Navigation Display
Figure 4-39).
The Direction Indicator comprises a compass, numerical direction indication, heading
bug, Ground Track Marker (when GPS ground track information is available), rate of turn
indicator, and aircraft ownship symbol.
Magnetic Heading
Selected Heading Field
Aircraft Ownship Symbol
Evolution Backup Display Pilot's Guide
Heading Bug
Compass Scale
091-00027-001 REV A
8/27/14 8:51 AM
