NOTE
The Altitude Tape can also be turned off for screen
declutter. Setting will be retained when EBD is
turned off.
NOTE
When the Airspeed Tape is disabled, the numerical
display of the selected airspeed remains An installer
can disable and remove the Selected Airspeed Field
from the display.
Figure 4-9
Editing Airspeed Tape Display
Page 4-12
091-00027-001 Rev A EBD Pilots Guide V&H .indb 12

4.2.2.1. Airspeed Display

In some configurations, such as a stand-alone EBD, the airspeed tape can be turned off
at the pilot's discretion to facilitate screen declutter. This setting will be retained when
the EBD system is turned off then powered on again.
Hide/Display Airspeed Tape
1. Press MENU Button.
2. Rotate Top Knob until first Menu Key displays TPS (Figure 4-9).
3. Press TPS Menu Key.
TPS label and EDIT VALUE label (above Top Knob) appear in magenta.
Rotate Top Knob to the desired value: ENABLE or DISABLE (Figure 4-10).
4.
5. Press MENU Button to exit.
Figure 4-10
Airspeed Tape Disabled
Evolution Backup Display Pilot's Guide 091-00027-001 REV A
