6.10. Warning, Caution, and Advisory Summary

WARNINGS
Figure 6-9
Battery Countdown
Figure 6-11
Attitude Fail
091-00027-001 REV A
091-00027-001 Rev A EBD Pilots Guide V&H .indb 17
Presented when the EBD is operating on the internal battery. The countdown timer begins at 15
seconds and is then replaced by the ON BAT annunciation with the battery's % charge remaining.
NOTE
Figure 6-10
If the battery temperature is less than 0° C, the countdown timer will begin at 10 minutes.
Battery Charge Remaining
Presented when the EBD has determined that the associated function is invalid or failed and should
not be used. The data is removed from the display and replaced by a red X over the affected display
feature.
Figure 6-12
Direction Indicator Fail
Evolution Backup Display Pilot's Guide
Page 6-17
