Aspen Avionics Evolution Backup Display EFD1000 Pilot's Manual page 61

WARNING
Whenever there is a new altimeter setting, set the EDB
and other altimeters within the aircraft.
091-00027-001 REV A
091-00027-001 Rev A EBD Pilots Guide V&H .indb 7
Set the Barometric Pressure
1. Press the BARO Hot Key. The BARO label above the Right/Top Knob and
Barometric Pressure Setting Field appear in magenta - enabled for editing
(Figure 3-6).
2. Rotate the Right/Top Knob clockwise to increase or counterclockwise to
decrease the value of the Barometric Pressure Setting Field.
3. Once the correct value is selected, press the BARO Hot Key or any knob,
button/key to exit the BARO function. After 10 seconds of inaction or if any
other button/key is pressed, the BARO function is disabled and the Right/Top
Knob returns to normal operation (Figure 3-7).
Figure 3-6
BARO Setting
Field Enabled
Figure 3-7
BARO Setting
Field Disabled
Evolution Backup Display Pilot's Guide
Page 3-7
