Attitude Display - Aspen Avionics Evolution Backup Display EFD1000 Pilot's Manual

33
32
35
34
Figure 2-16
Attitude Display Components
091-00027-001 REV A
091-00027-001 Rev A EBD Pilots Guide V&H .indb 19

2.3.2. Attitude Display

23 22
19
The Attitude Display includes an Attitude Director Indicator (ADI), an Airspeed tape, an
20
Altimeter tape, an Altitude Alerter, and Radio Altitude (Table 2-9 and Figure 2-16), (see
21
Chapter 4, Reference Guide for more details).
16
24
17
25
26
Table 2-9
Attitude Display Components
Evolution Backup Display Pilot's Guide
ATTITUDE DISPLAY
Attitude Display
16
Aircraft Reference Symbol
17
19 Roll Pointer
20 Slip/Skid Indicator
Altitude Tape
21
Selected Altitude Field
22
Altitude Alerter
23
Numerical Altitude Value, Altitude Drum/Pointer
24
25 Altitude Trend Vector
26 Altitude Bug
32 Airspeed Tape
Selected Airspeed Field
33
Airspeed Bug
34
Numerical Airspeed Value, Airspeed Drum/Pointer
35
Page 2-19
