EFD1000 (Pro) AIRPLANE FLIGHT MANUAL SUPPLEMENT
The information contained in this Supplement must be
attached to the FAA Approved Airplane Flight Manual when
the Aspen EFD1000 Electronic Flight Instrument System
PRO MODEL is installed in accordance with AML STC
SA10822SC.
The information in this Supplement supplements or
supersedes the information in the FAA Approved Airplane
Flight Manual only as set forth herein.
For limitations, procedures, and performance data not
contained in this Supplement, consult the Airplane Flight
Manual.
Listed on Aspen EFD1000 Approved Model List (AML)
Listed on Aspen EFD1000 Approved Model List (AML)
DOCUMENT # A-01-175-00
FAA APPROVED
Date: March 17, 2008
Aspen Avionics, Inc.
5001 Indian School NE
Albuquerque, NM 87110 USA
Document A-01-175-00 Revision B
FAA APPROVED
Airplane Make:
Airplane Model:
Airplane Registration Number:
Airplane Serial Number:
PAGE 1 OF 41
EFD1000 (Pro) Airplane Flight Manual Supplement
© Copyright 2008 Aspen Avionics Inc.
REVISION B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EFD1000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Aspen Avionics EFD1000

  • Page 1 For limitations, procedures, and performance data not contained in this Supplement, consult the Airplane Flight Manual. Airplane Make: Listed on Aspen EFD1000 Approved Model List (AML) Airplane Model: Listed on Aspen EFD1000 Approved Model List (AML) Airplane Registration Number: Airplane Serial Number:...
  • Page 2 EFD1000 (Pro) Airplane Flight Manual Supplement Document Revisions Document Pages Description of Change Approval Revision Revised Internal Release 1160 S. Frances FAA APPROVED Release 1267 Prepared Original Release Authorization signatures on file. See ECO for release date and Reviewed Release Date: 3/3/08 dispositions.
  • Page 3: Table Of Contents

    EFD1000 (Pro) Airplane Flight Manual Supplement TABLE OF CONTENTS GENERAL ............................5 ........................5 YSTEM VERVIEW LIMITATIONS ............................6 ........................6 OFTWARE ERSIONS ........................6 IRSPEED IMITATION & C ..................... 6 EIGHT ENTER OF RAVITY RSM GPS U ......................... 6 SAGE .......................
  • Page 4 EFD1000 (Pro) Airplane Flight Manual Supplement INTENTIONALLY LEFT BLANK DOCUMENT # A-01-175-00 PAGE 4 OF 41 REVISION B FAA APPROVED Date: March 17, 2008 © Copyright 2008 Aspen Avionics Inc.
  • Page 5: General

    Course and Heading values set by the pilot on the EFD1000, the same as is done with a mechanical HSI. When interfaced to a compatible GPS system, the EFD1000 can convert the digital GPS steering (GPSS) signals that are output from the GPS into analog GPSS signals that are compatible with the autopilot heading mode.
  • Page 6: System Overview Limitations

    The maximum approved operating airspeed for this system is 210 KTS (242 MPH). Weight & Center of Gravity Installation of the EFD1000 system may result in a small net change to the aircraft empty weight and associated moment arm. Refer to the revised weight and balance records carried in the aircraft for details.
  • Page 7: Placards And Decals

    “RSM GPS REVERSION EMER USE ONLY” Seaplane Operation The EFD1000 system may not be able to align when on water as a function of the wave action being experienced by the aircraft. When aligning on water, always perform a visual verification of the attitude reference with a secondary source, such as a mechanical gyro or the horizon.
  • Page 8: Emergency And Abnormal Procedures

    “AHRS: RESET?” LINE SELECT KEY ...... PRESS “AHRS: RESET?” LINE SELECT KEY ...... PRESS AGAIN TO CONFIRM RESET NOTE: When the EFD1000 AHRS is reset in flight, it performs an abbreviated initialization. During the initialization, the aircraft should not be subjected to excessive turn rates.
  • Page 9: Loss Of External Power

    EFD1000 (Pro) Airplane Flight Manual Supplement Loss of External Power In the event that external power to the unit is degraded or fails, the EFD1000 will automatically switch to its internal battery. When operating on internal battery, the display backlight intensity is capped at a value of 70.
  • Page 10: Abnormal Shutdown Procedure

    EFD1000 (Pro) Airplane Flight Manual Supplement Abnormal Shutdown Procedure Circuit Breaker ..............PULL REV Button ................ HOLD UNTIL DISPLAY BLANKS Warning, Caution, and Advisory Summary WARNINGS ON BAT Red annunciation presented whenever the EFD1000 is operating on the internal battery. Will be accompanied by an indication of the estimated battery charge remaining.
  • Page 11 EFD1000 (Pro) Airplane Flight Manual Supplement CAUTIONS RSM GPS Amber annunciation presented REVERSION whenever the EFD1000 reverts to EMER USE RSM GPS data and indicates that ONLY the RSM GPS is the current GPS source. RSM GPS usage is limited to “EMER USE ONLY”...
  • Page 12: Normal Procedures

    Before Taxi Checks EFIS MASTER (If installed) ..........ON Avionics and Instruments ..........SET as desired NOTE: The AHRS will perform an internal test during EFD1000 power up. The aircraft should remain stationary during the AHRS power up and alignment sequence.
  • Page 13: Performance

    EFD1000 (Pro) Airplane Flight Manual Supplement Performance No change. DOCUMENT # A-01-175-00 PAGE 13 OF 41 REVISION B FAA APPROVED Date: March 17, 2008 © Copyright 2008 Aspen Avionics Inc.
  • Page 14: System Description

    System Description General The EFD1000 system is a flat-panel LCD primary flight instrument that presents the pilot with displays of attitude, airspeed, altitude, vertical speed, slaved compass, slip/skid, and rate of turn information. The display head incorporates a solid-state Air Data and Attitude Heading Reference System (ADAHRS) to provide data for the flight instruments.
  • Page 15 System) or 25.6V (28V Electrical System) the EFD will automatically switch to its internal battery (e.g. aircraft charging system failure). The EFD1000 internal battery will provide at least 30 minutes of power when it is fully charged. The battery provides power to the display head, RSM and emergency GPS.
  • Page 16 EFD1000 (Pro) Airplane Flight Manual Supplement Display Screen and Control Layout 6.2.3 CDI Source Control Dual-Line Bearing Pointer Source Select Micro SD Card slot Automatic Dimming Photocell Attitude Indicator Aircraft Symbol Single Cue Flight Director (optional – compatible autopilot required)
  • Page 17 The home state for the right knob is “HDG.” Setting Flight Instruments 6.2.5 The following procedures are used to adjust pilot-editable data on the EFD1000: Heading Bug Set To set the heading bug, repeatedly PUSH the right control knob until the HDG field is enabled for editing.
  • Page 18 EFD1000 (Pro) Airplane Flight Manual Supplement Minimums Set To set the MINIMUMS alert, repeatedly PUSH the right control knob until the MIN field is enabled for editing. ROTATE the knob to the desired setting. The MIN field must first be enabled via the Hot Keys before it may be adjusted.
  • Page 19 EFD1000 (Pro) Airplane Flight Manual Supplement Hot Key Operation 6.2.7 During normal operations, the five line select soft-keys on the lower right side of the display bezel are referred to as “Hot Keys.” Hot Keys provide single-action access to frequently used functions. An electronic legend adjacent to each Hot Key indicates its hot key function.
  • Page 20 CDI Nav Source display field. If the integrated radio is not reporting its current state to the EFD1000, such as when the equipment is OFF, failed, or a GPS waypoint has not been programmed, the EFD1000 will default to the VLOC mode.
  • Page 21 Map Range Control 6.2.10 The EFD1000 basemap range may be set to ranges of 2.5, 5, 10, 15, 20, 30, 40, 60, 80, 100, and 200 nautical miles. Map range is measured from the own ship position to the outside of the compass arc.
  • Page 22: Primary Flight Instruments

    EFD1000 (Pro) Airplane Flight Manual Supplement Display Reversion Control and Abnormal Shutdown 6.2.11 Single PFD installations do not have a display reversion capability that can be activated by the REV button. As such, the reversion function is inoperative in single display installations.
  • Page 23 EFD1000 (Pro) Airplane Flight Manual Supplement Slip / Skid Indicator Slip / skid is indicated by the lateral position of the white rectangle under the roll pointer. One rectangle width is equivalent to one ball width of a conventional inclinometer.
  • Page 24 EFD1000 (Pro) Airplane Flight Manual Supplement Airspeed Indicator 6.3.3 Airspeed is indicated by a moving airspeed tape against a fixed position airspeed pointer. A digital, rolling drum readout indicating airspeed values to the closest one knot or mile per hour is provided adjacent to the fixed pointer. Tick marks are provided on the airspeed tape every 10 knots (or mph if so configured).
  • Page 25 EFD1000 (Pro) Airplane Flight Manual Supplement Speed Value Description Marker Red Line A Red line is displayed across the airspeed tape at the aircraft never exceed speed (V Blue Line Multi Engine Aircraft Only. A blue line is displayed across the airspeed tape...
  • Page 26 EFD1000 (Pro) Airplane Flight Manual Supplement adjacent to the fixed pointer. Minor tick marks are provided on the tape at 20 foot intervals, and major tick marks are provided at 100 foot intervals. The thousands and ten-thousands digits are larger than other digits on the tape. Negative altitudes are indicated by a “-“...
  • Page 27: Navigation Flight Instruments

    The traditional HSI is an instrument which combines a Direction Indicator overlaid with a rotating Course Deviation Indicator (CDI). The HSI on the EFD1000 can be presented in either a full 360 degree compass rose mode, or in a 100 degree ARC format.
  • Page 28 EFD1000 (Pro) Airplane Flight Manual Supplement Figure 21 - 360 Compass Mode Within the ARC mode, the pilot may select (via the main menu) between two different formats of CDI presentation – ARC HSI mode and ARC CDI mode. The ARC HSI mode, presents traditional rotating CDI symbology which resembles that used in the HSI 360 Compass mode.
  • Page 29 Figure 28 - Off Scale VDI Auto Course Control The pilot may configure the EFD1000 (via the main menu) to enable “Auto Course Select” whereby a connected GPS will automatically set the course (CRS) value whenever the GPS is auto sequencing between waypoints. This capability relieves the pilot from manually setting the course at each waypoint transition along a GPS route.
  • Page 30 Figure 30 - GPS Annunciations GPS Track Indicator Whenever the EFD1000 is connected to a compatible GPS a track indicator is provided. Track is indicated as a blue diamond rendered on the compass scale at the value that corresponds to the current aircraft track.
  • Page 31: Situational Awareness Map Display

    (if coupled to a GPS waypoints) and either the station identifier or the tuned frequency for a VLOC radio. This data is only presented when it is reported to the EFD1000 by the connected equipment, and thus is not available in all installations.
  • Page 32 EFD1000 (Pro) Airplane Flight Manual Supplement Figure 33 - Map Feature Symbols Flight Plan When a flight plan is received from a compatible GPS system the Basemap will show the current and future flight plan waypoints and legs. The active leg waypoint and its associated identifier are displayed in magenta.
  • Page 33: Autopilot Integration

    This assures that the navigation information presented on the EFD1000 is the same as that being provided to the autopilot. This arrangement also eliminates the need for external autopilot navigation source selector switches and relays that were previously used to select which navigation radio would be connected to the autopilot.
  • Page 34 The EFD1000 translates GPS steering commands received over an ARINC 429 bus into a signal that is compatible with the autopilot Heading channel. Thus, by selecting GPSS on the EFD1000 and the Heading mode of the autopilot, the autopilot is able to fly GPS Steering commands.
  • Page 35 Typical Autopilot Operations Whenever the EFD1000 installed configuration includes connections to GPS, VLOC and autopilot systems, the EFD1000 acts as a conduit of data between the navigation radios and the autopilot system. This configuration enables any navigation sensor available for display on the EFD system to be coupled to the autopilot.
  • Page 36 1. With a valid flight plan programmed in the GPS, use the CDI Nav Source Select Switch to couple the GPS to the HSI (See 6.2.8). 2. With GPSS OFF, set the EFD1000 heading bug to a value that will intercept the active leg of the flight plan.
  • Page 37 1. Use the CDI Nav Source Select Switch, couple a tuned/valid ILS radio frequency to the HSI, and set the desired approach course (See 6.2.8). 2. Set the EFD1000 heading bug to a value that will intercept the desired course, or as instructed by ATC 3.
  • Page 38: Main Menu Operation

    EFD1000 (Pro) Airplane Flight Manual Supplement 6. Once cleared for the ILS approach, couple the EFD1000 HSI to the tuned ILS (if not done automatically by the coupled radio) and arm the autopilot’s Approach mode. 7. Monitor the CDI localizer deflection and verify that upon intercepting the localizer that the autopilot switches to Approach NAV Capture, turns to track the localizer course, and arms the glide slope.
  • Page 39 EFD1000 (Pro) Airplane Flight Manual Supplement Figure 39 - Main Menu Line select keys To exit the edit mode press the adjacent line select key, press the right control knob, or leave the menu by pressing the MENU button. Menu Options 6.7.2...
  • Page 40 View the External Power Source Voltage • View the Internal Battery Status System Status The SYSTEM STATUS page is used to display information about the EFD1000 system and software. From the SYSTEM STATUS page the pilot may: • View the Main Application Processor software version •...
  • Page 41: List Of Acronyms

    EFD1000 (Pro) Airplane Flight Manual Supplement List of Acronyms ACU ................Analog Converter Unit AFMS ................Airplane Flight Manual Supplement AHRS ................Attitude Heading Reference System BARO ................Barometric Pressure Setting BC .................. Back Course BP .................. Bearing Pointer CDI ................. Course Deviation Indicator CM ..................
