Figure 2-15
EBD Display Areas
091-00027-001 REV A
091-00027-001 Rev A EBD Pilots Guide V&H .indb 17

2.3. Display

The EBD Basic is a digital backup for the Attitude Indicator and DG. The left half presents
an Attitude Display and the right half contains a Navigation Display (Figure 2-15 and
Table 2-8). Between the two halves is the Data Bar. The Data Bar contains a dedicated
display of real-time winds, Outside Air Temperature (OAT), True Airspeed (TAS), and GPS
Ground Speed (GS).
Table 2-8
EBD Display Areas
Figure 2-15a
EBD Display areas with callouts
Evolution Backup Display Pilot's Guide
Attitude Display
Data Bar
Navigation Display
Page 2-17
