Table 1
Evolution Backup Display – Basic, Landscape Version – Knobs , Buttons, and Keys
091-00027-001 REV A
091-00027-001 Rev A EBD Pilots Guide V&H .indb 17
Example
PWR (Power) Button, Range Buttons, MENU Button
Five keys across the top of the display
Top Button, CDI Navigation Source Select Button (Middle
Button), Bottom Button
Top (HDG) Knob, Bottom (IAS) Knob
Navigation Display
Data Bar
Attitude Display
Evolution Backup Display Pilot's Guide
NOTE
As the number of colors used on the display is limited,
to ensure adequate color differentiation under all
lighting conditions, there are a few cases where a
given color is used in a slightly different context than
described in Table 2.
