Cpos (Sdh/Sonet) Interface Module; Hmim-1Cpos - HPE FlexNetwork MSR Series Manual

Interface LEDs
Figure 96 HMIM-1POS front panel
Table 132 LED description
LED
LINK/ACT
LP/AL
Fiber ports, optical fibers, and the connection methods
For more information about fiber ports, optical fibers, and the connection methods, see

CPOS (SDH/SONET) interface module

•

HMIM-1CPOS

HMIM-1CPOS
Introduction
The 1-port
STM-1/OC3-compliant multi-channel interface. It provides an interface rate of up to 155.52 Mbps.
You can set E1 or T1 working mode for the HMIM-1CPOS interface module.
The HMIM-1CPOS interface module is installed in an HMIM slot to receive and transmit data on
STM-1 channelized POS interface and to communicate with the CPU through the PCI interface.
The HMIM-1CPOS provides the following features:
•
Multiple transceiver modules.
•
Clear channel (unframed) E1 or T1
•
Fractional (framed) E1 or T1
A maximum of 256 × 64 kbps logical channels
•
Interface specifications
Table 133 Interface specifications
Item
Interface
standard
Number of
interfaces
Description
•
On means carrier signal has been received.
•
Flashing means data is being received or/and transmitted.
•
Off means no carrier signal has been received.
•
On means the interface is in a loopback.
•
Off means no loopback or alarm is present.
•
Flashing means an alarm indication signal (AIS), loss of frame
alignment (LFA) signal, or remote alarm indication (RAI) signal is
present.
channelized SDH/SONET
Specification
SONET OC-3/SDH STM-1
1
interface module
83
"Fiber
(HMIM-1CPOS) provides
port."
one
