Figure 172 Connecting a bank dumb terminal device
Dumb terminal
adapter cable
8ASE
16ASE
•
If the interface of the remote device is a D25/D9 interface, use the AUX cable to connect the
RJ45 interface on the MIM-8ASE/MIM-16ASE/FIC-8ASE/FIC-16ASE interface module. The
sequence is shown in the following figure:
Figure 173 Connecting a modem
AUX cable
8ASE
16ASE
Straight-
Dumb terminal adapter
through cable
Bank dumb terminal
Modem
164
device
