Item
Cable type
Min. baud rate (bps)
Max. baud rate (bps)
Service supported
Interface LEDs
Figure 151 FIC-8ASE panel
Figure 152 FIC-16ASE panel
The FIC-8ASE/FIC-16ASE has one LED for each port. On means a link is present. Off means data is
being transmitted and/or received.
Interface cables and connection methods
For more information about asynchronous serial port cables, see

Voice interface module

•
FIC-4FXS
•
FIC-4FXO
•
FIC-4E&M
•
FIC-24FXS
•
FIC-2VE1
•
FIC-2VT1
•
FIC-1VE1
•
FIC-1VT1
Specification
FIC-8ASE
•
AUX cable
•
Ethernet straight-through cable
•
FIC-8ASE/FIC-16ASE dumb terminal cable
300
115.2 k
•
Dialup through modem
•
Backup
•
Terminal access service
•
Asynchronous leased line
129
FIC-16ASE
"Asynchronous serial ports."
