Table 192 LED description
LED
LINK/ACT
LP/AL
Note:
AIS = Alarm indication signal; LFA = loss of frame alignment; RAI = Remote alarm indication
Interface cables and connection methods
For more information about E1 interface cables, see

FIC-8E1

Introduction
The 8-port channelized E1/PRI interface module (FIC-8E1) transmits, receives, and processes eight
channels of E1 data traffic. In addition, you can use the module for other purposes, such as CE1
access and the ISDN PRI function.
NOTE:
For a FIC-8E1 module, the system automatically creates a serial interface for each timeslot bundle
formed on a controller E1 interface.
Interface specifications
Table 193 Interface specifications
Item
Connector
Number of connectors
Interface standard
Interface rate
Cable type
Operating mode
Supported service
Description
•
On means carrier signal has been received.
•
Flashing means data is being received or/and transmitted.
•
Off means no carrier signal has been received.
•
On means the interface is in a loopback.
•
Flashing means an AIS, LFA, or RAI alarm signal is present.
•
Off means no loopback or alarm is present.
Specification
D68
1
G.703
2.048 Mbps
75-ohm 8E1 conversion cable
•
E1, CE1, ISDN PRI
•
Backup
•
Terminal access service
•
ISDN PRI
"E1 interface."
