FIC-1VE1

Introduction
The 1-port E1 voice interface module (FIC-1VE1) handles dense voice signals in VoIP system. It
provides a CE1/PRI/R2 port that allows access of a maximum of 30 channels of voice signals.
Interface specifications
Table 218 Interface specifications
Item
Connector
Number of connectors
Operating mode
Interface rate
Cable
Supported service
Interface LEDs
Figure 159 FIC-1VE1 panel
Table 219 LED description
LED
LINK/ACT
LP/AL
Note:
AIS = Alarm indication signal; LFA = loss of frame alignment; RAI = Remote alarm indication
Interface cables and connection methods
For more information about E1 interface cables and connection methods, see
Specification
D15
1
CE1
ISDN PRI
R2
2.048 Mbps
•
E1 120-ohm balanced twisted pair cable
•
75ohm-to-120ohm adapter
•
Network interface connector
•
R2 signaling
•
DSS1 signaling
•
IP Fax
•
General VoIP features in Comware
Description
•
On means carrier signal has been received.
•
Flashing means data is being received or/and transmitted.
•
Off means no carrier signal has been received.
•
On means the interface is in a loopback.
•
Flashing means an AIS, LFA, or RAI alarm signal is present.
•
Off means no loopback or alarm is present.
135
"E1 interface."
