Interface LEDs
Figure 143 FIC-8E1 (75-ohm) panel
Table 194 LED description
LED
LINK/ACT
LP/AL
Note:
AIS = Alarm indication signal; LFA = loss of frame alignment; RAI = Remote alarm indication
Interface cables and connection methods
For more information about E1 interface cables, see
FIC-4T1-F
Introduction
The FT1 operating mode supported by the T1-F modules allows only one n × 64 kbps or n × 56 kbps
bundle to be formed on each interface, where n = 1 to 24. The FIC-4T1-F modules do not support the
PRI mode.
Interface specifications
Table 195 Interface specifications
Item
Connector
Number of connectors
Interface standard
Interface rate
Cable type
Operating mode
Supported service
Description
•
On means carrier signal has been received.
•
Flashing means data is being received or/and transmitted.
•
Off means no carrier signal has been received.
•
On means the interface is in a loopback.
•
Flashing means an AIS, LFA, or RAI alarm signal is present.
•
Off means no loopback or alarm is present.
Specification
RJ-45
•
4
•
G.703/T1 102
•
G.704
•
AT&T TR 54016
•
AT&T TR 62411
•
ANSI T1.403
1.544 Mbps
T1 cable (100-ohm straight-through shielded cable)
FT1
•
Backup
•
Leased line
120
"E1
interface."
