5. Execute the display cellular [slot]/0 all command after the router is started. When "SIM Status
= OK" appears in the output information, the SIM module is identified.

SIC-4G-LTE-V (JG742B)

The SIC-4G-LTE-V (JG742B) module provides access to 4G WLANs. It supports the following
services:
•
LTE.
•
EVDO Release 0 & A.
•
UMTS.
•
HSPA+.
•
DC-HSPA+.
•
Quad-band EDGE.
•
GPRS.
•
GSM.
•
GNSS.
Interface specifications
Table 61 Interface specifications
Item
Connector type
Number of
connectors
Interface standard
Cable type
Services
Specification
•
TNC: Antenna connector for accessing WLANs.
•
SMA: Antenna connector for accessing GNSS.
•
Mini USB Type AB: For connecting to third-party WLAN debugging and testing
software such as CAIT of Qualcomm.
2 × TNC.
•
• 1 × SMA.
1 × Mini USB Type AB.
•
•
TNC: LTE, UMTS, HSPA+, CDMA 1x, EVDO Release 0 & A, Quad-band EDGE,
GPRS, and GSM.
•
SMA: GNSS.
•
Mini USB Type AB: Support for USB devices.
•
TNC: None.
•
SMA: Flexible 174 sized cable.
•
Mini USB Type AB: USB console cable.
•
LTE.
•
EVDO Release 0 & A.
•
UMTS.
•
HSPA+.
•
DC-HSPA+.
•
Quad-band EDGE.
•
GPRS.
•
GSM.
•
GNSS.
