Interface cables and connection methods
For more information about FXS / FXO interface cables and connection methods, see
"ADSL/BS/FXS/FXO/AM/FCM
FIC-4E&M
Introduction
The 4-port voice E&M analog trunk interface module (FIC-4E&M) processes and transmits over data
communications networks voice signals for 4 E&M analog trunks.
Interface specifications
Table 210 Interface specifications
Item
Connector
Number of connectors
Cable
Interface standard
Dial-up mode
Bandwidth
Interface LEDs
Figure 155 FIC-4E&M panel
Table 211 LED description
LED
LINK
ACT
Interface cables and connection methods
For more information about E&M Interface cables and connection methods, see
interface."
Specification
RJ-45
•
4
•
Telephone cable with ferrite core
•
E&M trunk cable (only for E&M modules, made on site)
•
ITU Q.512-compliant subscriber circuit interface (FIC-4FXS)
•
ITU Q.552-compliant loop trunk interface (FIC-4FXO)
•
ITU K.20-compliant overcurrent protection
Dual-tone multifrequency (DTMF), compliant with GB3378
(Pulse dial is not available.)
300 Hz to 3400 Hz
Description
•
Off means no link is present.
•
On means a link is present.
•
Off means the channel is idle.
•
On means there is call activity.
131
"E&M interface."
