Item
Number of connectors
Interface standard
Interface rate
Interface cable type
Operating mode
Supported service
Interface LEDs
Figure 69 MIM-1CT3 panel
Table 100 LED description
LED
LINK/ACT
LP/AL
Note:
AIS = Alarm indication signal; LFA = loss of frame alignment; RAI = Remote alarm indication
Interface cables and connection methods
For more information about T3 interface cables and connection methods, see

xDSL interface module

•

MIM-1SHL-4W

MIM-1SHL-4W
Introduction
The 1-port dual-pair G.SHDSL interface module (MIM-1SHL-4W) uses trellis coded pulse amplitude
modulation (TCPAM) coding and provides symmetric rates up to 4.624 Mbps. The transmission rate
of the interface can automatically adapt to line distances and conditions.
Description
•
On means the carrier signal has been received.
•
Off means no carrier signal has been received.
•
Flashing means data is being transmitted or/and received.
•
On means the interface is in a loopback.
•
Flashing means an AIS, LFA, or RAI alarm signal is present.
•
Off means no loopback or alarm is present.
64
Specification
2
•
G.703
•
G.704
•
G.752
•
AT&T TR 54014
•
AT&T TR 62415
•
ANSI T1.107
44.736 Mbps
E3/T3 cable (75-ohm coaxial cable)
T3
CT3
T3 leased line
"E3/T3 interface."
