MIM-2SAE/MIM-4SAE/MIM-8SAE

Introduction
The 2/4/8-port enhanced high-speed synchronous/asynchronous serial interface module
(MIM-2SAE/MIM-4SAE/MIM-8SAE) functions the same as SA modules except that the SAE
modules support additional protocols, for example, RS449, X.21, and RS530.
Interface specifications
Table 103 Interface specifications
Item
Connector
Number of connectors
Interface standard and
operating mode
Minimum baud rate
(bps)
Maximum baud rate
(bps)
Cable
Supported service
Specification
Synchronous
D28
2 (MIM-2SAE)
4 (MIM-4SAE)
8 (MIM-8SAE)
V.35, RS449, X.21,
V.24
RS530
DTE, DCE DTE, DCE
1200 1200
64 k 2.048 M
•
V.24 (RS232) DTE cable
•
V.24 (RS232) DCE cable
•
V.35 DTE cable
•
V.35 DCE cable
•
X.21 DTE cable
•
X.21 DCE cable
•
RS449 DTE cable
•
RS449 DCE cable
•
RS530 DTE cable
•
RS530 DCE cable
•
DDN leased line
•
Terminal access service
66
Asynchronous
RS232
300
115.2
•
Dialup through modems
•
Backup
•
Asynchronous leased line
•
Dumb terminal access
