Table 110 LED description
LED
LINK
ACT
Interface cables and connection methods
For more information about BSV interface cables and connection methods, see
interface."

MIM-2FXO and MIM-4FXS/MIM-4FXO

Introduction
The MIM-2FXO and MIM-4FXS/MIM-4FXO modules transfer voice signals over data communication
networks.
•
The 4-port voice subscriber circuit interface module (MIM-4FXS) can provide access for and
process 2/4 channels of ordinary analog phone, fax, or AT0 loop trunk of telephone exchange.
•
The 2/4-port voice AT0 analog trunk interface module (MIM-2FXO/MIM-4FXO) can provide
access for and process 2/4 channels of common user lines of telephone exchange.
Interface specifications
Table 111 Interface specifications
Item
Connector
Number of connectors
Cable
Interface standard
Dial-up mode
Bandwidth
Interface LEDs
Figure 78 MIM-2FXO panel
Description
•
Off means no link is present.
•
On means a link is present.
•
Slowly flashing means data is being transmitted or received on B1 channel.
•
Fast flashing means data is being transmitted or received on B2 channel.
•
Steady On means data is being transmitted or received on both B1 and B2
channels.
•
Steady Off means no data is being transmitted or received.
Specification
RJ-45
•
2 (MIM-2FXO module)
•
4 (MIM-4FXS/MIM-4FXO module)
•
Telephone cable with ferrite core
•
E&M trunk (for E&M module, which should be made by users
depending on the actual needs at the site.)
•
ITU Q.512-compliant subscriber circuit interface (MIM-4FXS)
•
ITU Q.552-compliant loop trunk interface (MIM-2FXO/MIM-4FXO)
•
ITU K.20-compliant overcurrent and overvoltage protection
DTMF (Dual-Tone Multi-Frequency) but not pulse dial-up
300 Hz to 3400 Hz
71
