MIM-16FXS

Introduction
The 16-port loop trunk interface module (MIM-16FXS) provides access for 16 channels of analog
voice signals over data communication networks. The module provides 16 FXS interfaces. FXS
interfaces are analog subscriber line interfaces that provide analog telephone and fax access and
also can connect AT0 loop trunks of exchanges.
Interface specifications
Table 107 Interface specifications
Item
Connector type
Number of connectors
Interface standard
Cable type
Dial-up mode
Bandwidth
Interface LEDs
Figure 76 MIM-16FXS panel
Table 108 LED description
LED
LINK/ACT
Interface cables and connection methods
For more
"ADSL/BS/FXS/FXO/AM/FCM
Specification
RJ-11
16 (FXS interfaces)
Subscriber circuit interface (FXS) compliant with ITU Q.512.
Over-current and over-voltage protection compliant with ITU K.20.
Telephone cable with ferrite core
DTMF, compliant with GB3378 (Pulse dial-up is not available.)
300 to 3400 Hz
Description
•
Off means no link is present.
•
Steady green means a link is present and a call connection is being established.
•
Flashing yellow means a link is present and there is a call activity.
information about
interface."
FXS interface cables
69
and connection methods, see
