SIC-1BS

Introduction
The 1-port ISDN BRI S/T interface module (SIC-1BS) transmits and processes ISDN BRI S/T traffic
flows. It can operate in dial-up or leased line mode.
Interface specifications
Table 35 Interface specifications
Item
Connector
Number of connectors
Cable type
Interface standard
Working mode
Supported services
Interface LEDs
Figure 24 SIC-1BS panel
Table 36 LED description
LED
B1
B2
ACT
On
Interface cables and connection methods
For more
"ADSL/BS/FXS/FXO/AM/FCM
Description
RJ-45
1
Telephone cable with ferrite core
•
•
•
•
•
•
•
•
•
•
Description
•
Off indicates the B1 channel is idle.
•
Flashing indicates the B1 channel is being used for data communication.
•
Off indicates the B2 channel is idle.
•
Flashing indicates the B1 channel is being used for data communication.
•
Off indicates the inactive state.
•
Steady on indicates the active state.
•
Off indicates the interface module is powered off.
•
On indicates the interface module is powered on.
information about
interface."
ITU-T I.430
Q.921
Q.931
ISDN Dial-up
ISDN leased line
ISDN
ISDN supplementary services
Multi-subscriber number
Sub-address
Backup
BS Interface cables
20
and connection methods, see
