E1 interface

E1 cable appearance and applicable models
Table 237 E1 cable appearance and applicable models
Produ
ct
Description
numbe
r
HPE X260 E1
2*BNC 75 ohm
3m Router Cable
JD175A
HPE X260 E1
JD514A BNC 20m Router
Cable
JD516A
HPE X260 E1/2
BNC 75 ohm 40m
Router Cable
HPE X260 E1
RJ45 3m Router
JD509A Cable
JD517A HPE X260 E1
RJ45 20m Router
Cable
Cable Appearance
1-port E1
75-ohm cable
1 × D15 < ---- > 2 × BNC
1-port E1
120-ohm cable
1 × D15 < ---- > 1 × RJ45
149
Applicable
models
SIC-1E1-F
SIC-1EPRI
MIM-1E1
MIM-1E1-F
MIM-2E1
MIM-2E1-F
FIC-1E1
FIC-1E1-F
FIC-2E1
FIC-2E1-F
HMIM-2E1
SIC-1VE1
MIM-1VE1
MIM-2VE1
FIC-1VE1
FIC-2VE1
HMIM-1VE1
HMIM-2VE1
MIM-1E1
MIM-1E1-F
MIM-2E1
MIM-2E1-F
FIC-1E1
FIC-1E1-F
FIC-2E1
FIC-2E1-F
HMIM-2E1
SIC-1VE1
MIM-1VE1
MIM-2VE1
FIC-1VE1
FIC-2VE1
HMIM-1VE1
HMIM-2VE1
