HPE FlexNetwork MSR Series Manual page 124

Interface specifications
Table 191 Interface specifications
Item
Connector
Number of
connectors
Interface standard
Interface rate
Cable type
Operating mode
Supported service
Interface LEDs
Figure 140 FIC-2E1 panel
Figure 141 FIC-4E1 panel
Figure 142 FIC-4E1-F panel
Specification
FIC-2E1
D15
2
G.703, G.704
2.048 Mbps
•
E1 75-ohm unbalanced coaxial cable
•
E1 120-ohm balanced twisted-pair cable
•
120-ohm 4E1 adapter cable (FIC-4E1/FIC-4E1-F)
•
75-ohm 4E1 adapter cable (FIC-4E1/FIC-4E1-F)
•
Coaxial connector, network connector, 75-to-120-ohm adapter (with BNC
connector)
E1, CE1, ISDN PRI (only supported by the FIC-E1 modules)
FE1 (only supported by the FIC-E1-F modules)
•
Backup
•
Leased line
•
ISDN PRI (only supported by the FIC-E1 modules)
FIC-4E1/FIC-4E1-F
D25
1
118
