File Management

Save Menu

Key Sequence: File > Save
Save
a b c
d e f
g h i
j k l
m n o
p q r
s t u
v w x
y z - _
Back Space
Change
Save
Location
Change Type
Setup/JPG/...
Figure 4-6. Save Menu
BTS Master UG
Text Entry Keys: The top 5 keys are for text entry. The submenu keys for
Text Entry displays the characters (alphabet, hyphen, and underscore).
Press the
a b c / d e f
with a separate key for each of these letters. Characters can be entered by
using the rotary knob or by using the submenu keys.
The rotary knob scrolls through the characters in a pop-up window and
pressing the rotary knob enters a character. The menu returns to the
complete character set after each individual letter is entered.
Use the arrow keys to navigate within a name or character string. Use the
Shift key for capital letters. Press the Enter key or the rotary knob to finalize
a text entry.
Back Space: Use this key to delete a file name highlighted in blue or delete
individual characters.
Change Save Location: Press this submenu key to open the
"Save Location Menu".
Change Type: Press this submenu key to select what type of file is saved.
The options are the Measurement, Setup, or Jpeg. The file type can be
changed with the Up/Down keys or the rotary knob.
Setup (.stp): Setup files contain basic instrument information,
measurement mode setup details, measurement marker data, and
limit data.
Measurement (.spa): Contains the measurement data and opens
with Master Software Tools.
Jpeg (.jpg): Jpeg files contain a screen capture of the display.
Limit Lines (.lim): The Limit line file contains limit line data details.
