Service and Maintenance

Restoring Configuration Data from a Restoration Point

Important: Restoring an old configuration overwrites
the current configuration data.
Note: A configuration file that was created with an
older firmware version, may possibly not contain all of
the configuration data (for example, data for new
functions that were added by a firmware update).
Requirements
– Open configuration manager (existing connection to
the PBX web server)
– Inserted restoration point
Requirements
– Opened configuration manager (with an existing con-
nection to the PBX web server)
– Inserted restoration point
Steps to Take
1.
Open the page Administration
2.
Click Reset.
Requirements
– Open casing
Warning: Improper handling of the device can result
in life-threatening electrical shock.
Only a skilled electrician may open the casing and
perform installation work within an open casing or
service work using the buttons inside the casing.
If necessary, commission an authorised dealer to
perform this work.
Note: The buttons and LEDs are easily visible and
accessible on the front panel of the 19" casing
variants.
Note: This function requires performing the steps
rapidly. Make sure you are comfortable with the
procedure before you begin.
Steps to Take
1.
Press the "Reset" button. See
2.
Within the space of 2 seconds, push the "Default"
button and hold it.
76

Resetting the Configuration

Data backup.

Restoring Factory Settings

Fig. 63.
Steps to take
1.
Open the page Administration
2.
In the Configuration file list field under Restore old
configuration data, select the restoration point for
which configuration data should be restored.
Note: Under Restore old configuration data, addi-
tionally enable the checkbox Restore network set-
tings if you want to restore the network settings, as
well.
3.
Click Restore.
3.
Click OK.
The "Power" LED blinks in orange during a
restart.
If the LED lights up in green again, the restart is
complete and the PBX is ready for operation.
Further Steps
Create a new configuration.
The "Status" LED starts to quickly blink in red.
After a few seconds, the blinking of the "Status"
LED will slow down.
3.
Let go of the "Default" button.
The "Status" LED and the "Power" LED light up in
red and orange for several seconds/minutes
during the restart. See also the table on
If both LEDs light up in green again, the restart is
complete and the PBX is ready for operation.
Note: If the "Power" LED remains continuously lit in
red, an error has occurred. Please contact your
dealer or the manufacturer directly.
Further Steps
Check the configuration.
Note: If the old configuration is still present, you have
held the "Default" button for too long and must
therefore repeat the procedure.
Create a new configuration.
Data backup
Page 71.
