Parameter Descriptions
0-20 Display Line 1.1 Small
Option:
[2587 ] Inverse Interlock
[2827] Discharge Temperature
0-21 Display Line 1.2 Small
Option: Function:
Options are the same as in
0-20 Display Line 1.1 Small
[1614] Motor Current [A]
*
0-22 Display Line 1.3 Small
Option: Function:
Options are the same as in 0-20 Display
Line 1.1 Small.
[1610] Power [kW]
*
0-23 Display Line 2 Large
Option: Function:
Options are the same as in 0-20 Display
Line 1.1 Small.
[1613] Frequency [Hz]
*
0-24 Display Line 3 Large
Option: Function:
Options are the same as in
0-20 Display Line 1.1 Small.
[1662] Analog Input 53
*
0-25 My Personal Menu
Option: Function:
Define up to 20 parameters to include in the Q1
Personal Menu, accessible via the [Quick Menu] key on
the LCP. The parameters will be displayed in the Q1
Personal Menu in the order they are programmed into
this array parameter. Delete parameters by setting the
value to « 0000 ».
0-30 Unit for User-defined Readout
Option: Function:
It is possible to program a value to be shown in
the display of the LCP. The value will have a
linear, squared or cubed relation to speed. This
relation will depend on the unit selected (see
table above). The actual calculated value can be
read in 16-09 Custom Readout, and/or shown in
the display be selecting Custom Readout [16-09]
in 0-20 Display Line 1.1 Small to 0-24 Display Line 3
Large.
[0] None
*
[1] %
[5] PPM
[10] 1/min
[11] rpm
[12] Pulse/s
[20] l/s
MG34M302 - VLT
Operating Instructions VLT
Function:
®
is a registered Danfoss trademark/Commercial Compressor
®
CDS302 and CDS303
0-30 Unit for User-defined Readout
Option: Function:
[21] l/min
[22] l/h
[23] m³/s
[24] m³/min
[25] m³/h
[30] kg/s
[31] kg/min
[32] kg/h
[33] t/min
[34] t/h
[40] m/s
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[80] kW
[120] GPM
[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in²
[172] in WG
[173] ft WG
[180] HP
0-31 Min Value of User-defined Readout
Range:
0.00 Custom- [ -999999.99 -
ReadoutUnit par. 0-32
*
CustomRea-
doutUnit]
Function:
This parameter sets the
min. value of the custom
defined readout (occurs at
zero speed). Only possible
to set different from 0 is
when selecting a linear unit
in 0-30 Unit for User-defined
Readout. For Quadratic and
