Parameter Descriptions
3-51 Ramp 2 Ramp up Time
Range: Function:
Size [ 0.01 - Enter the ramp-up time, i.e. the
related 3600.00 acceleration time from 0 RPM to the rated
*
s] motor speed n
such that the output current does not
exceed the current limit in 4-18 Current
Limit during ramping. The value 0.00
corresponds to 0.01 s in speed mode. See
ramp-down time in 3-52 Ramp 2 Ramp
down Time.
Par . 3 − 51 =
3-52 Ramp 2 Ramp down Time
Range: Function:
Size [ 0.01 - Enter the ramp-down time, i.e. the
related 3600.00 deceleration time from the rated motor
*
s] speed n to 0 RPM. Choose a ramp-down
s
time such that no over-voltage arises in the
inverter due to regenerative operation of
the motor, and such that the generated
current does not exceed the current limit
set in 4-18 Current Limit. The value 0.00
corresponds to 0.01 s in speed mode. See
ramp-up time in 3-51 Ramp 2 Ramp up
Time.
Par . 3 − 52 =
3-60 Ramp 3 Type
Option: Function:
Select the ramp type, depending on
requirements for acceleration and
deceleration. A linear ramp will give constant
acceleration during ramping. An S-ramp will
give non-linear acceleration, compensating
for jerk in the application.
[0] Linear
*
[1] S-ramp Accelerates with lowest possible jerk.
Const Jerk
[2] S-ramp S-ramp based on the values set in 3-61 Ramp
Const Time 3 Ramp up Time and 3-62 Ramp 3 Ramp down
Time
NOTE
If [1] S-ramp Const Jerk is selected and the reference during
ramping is changed the ramp time may be prolonged in
order to realize a jerk free movement which may result in
a longer start or stop time.
Additional adjustment of the S-ramp ratios or switching
initiators may be necessary.
MG34M302 - VLT
Operating Instructions VLT
. Choose a ramp-up time
s
t acc s x n s RPM
ref RPM
t dec s x n s RPM
ref RPM
®
is a registered Danfoss trademark/Commercial Compressor
®
CDS302 and CDS303
3-61 Ramp 3 Ramp up Time
Range: Function:
Size [ 0.01 - Enter the ramp-up time, i.e. the
related 3600.00 s] acceleration time from 0 RPM to the
*
rated motor speed n
up time such that the output current
does not exceed the current limit in
4-18 Current Limit during ramping. The
value 0.00 corresponds to 0.01 s in
speed mode. See ramp-down time in
3-62 Ramp 3 Ramp down Time.
3-62 Ramp 3 Ramp down Time
Range: Function:
Size [ 0.01 - Enter the ramp-down time, i.e. the
related 3600.00 deceleration time from the rated motor
*
s] speed n to 0 RPM. Choose a ramp-down
s
time such that no over-voltage arises in the
inverter due to regenerative operation of
the motor, and such that the generated
current does not exceed the current limit
set in 4-18 Current Limit. The value 0.00
corresponds to 0.01 s in speed mode. See
ramp-up time in 3-61 Ramp 3 Ramp up
Time.
Par . 3 − 62 =
3-70 Ramp 4 Type
Option: Function:
Select the ramp type, depending on
requirements for acceleration and
deceleration. A linear ramp will give constant
acceleration during ramping. An S-ramp will
give non-linear acceleration, compensating
for jerk in the application
[0] Linear
*
[1] S-ramp Accelerates with lowest possible jerk.
Const Jerk
[2] S-ramp S-ramp based on the values set in 3-71 Ramp
Const Time 4 Ramp up Time and 3-72 Ramp 4 Ramp Down
Time.
NOTE
If [1] S-ramp Const Jerk is selected and the reference during
ramping is changed the ramp time may be prolonged in
order to realize a jerk free movement which may result in
a longer start or stop time.
Additional adjustment of the S-ramp ratios or switching
initiators may be necessary.
. Choose a ramp-
s
t dec s x n s RPM
ref RPM
