Parameter Descriptions
13-01 Start Event
Option: Function:
[5] Torque limit The torque limit, set in 4-16 Torque
Limit Motor Mode or 4-17 Torque Limit
Generator Mode, has been exceeded.
[6] Current limit The motor current limit, set in
4-18 Current Limit, has been
exceeded.
[7] Out of current The motor current is outside the
range range set in 4-18 Current Limit.
[8] Below I low The motor current is lower than set
in 4-50 Warning Current Low.
[9] Above I high The motor current is higher than set
in 4-51 Warning Current High.
[10] Out of speed range The speed is outside the range set in
4-52 Warning Speed Low and
4-53 Warning Speed High.
[11] Below speed low The output speed is lower than the
setting in 4-52 Warning Speed Low.
[12] Above speed high The output speed is higher than the
setting in 4-53 Warning Speed High.
[13] Out of feedb. range The feedback is outside the range set
in 4-56 Warning Feedback Low and
4-57 Warning Feedback High.
[14] Below feedb. low The feedback is below the limit set in
4-56 Warning Feedback Low.
[15] Above feedb. high The feedback is above the limit set in
4-57 Warning Feedback High.
[16] Thermal warning The thermal warning turns on when
the temperature exceeds the limit in
the motor, the frequency converter,
the brake resistor or the thermistor.
[17] Mains out of range The mains voltage is outside the
specified voltage range.
[18] Reversing The output is high when the
frequency converter is running
counter clockwise (the logical
product of the status bits "running"
AND "reverse").
[19] Warning A warning is active.
[20] Alarm (trip) A (trip) alarm is active.
[21] Alarm (trip lock) A (Trip lock) alarm is active.
[22] Comparator 0 Use the result of comparator 0.
[23] Comparator 1 Use the result of comparator 1.
[24] Comparator 2 Use the result of comparator 2.
[25] Comparator 3 Use the result of comparator 3.
[26] Logic rule 0 Use the result of logic rule 0.
[27] Logic rule 1 Use the result of logic rule 1.
MG34M302 - VLT
®
Operating Instructions VLT CDS302 and CDS303
13-01 Start Event
Option:
[28]
[29]
[33]
[34]
[35]
[36]
[37]
[38]
[39]
[40]
[41]
[42]
[43]
[44]
[45]
[46]
[47]
[48]
[50]
[51]
[60]
[61]
[94]
[95]
[96]
[97]
[98]
[99]
[100] RS Flipflop 6
[101] RS Flipflop 7
13-02 Stop Event
Select the boolean (TRUE or FALSE) input to activate Smart Logic
Control.
Option:
[0]
*
[1]
[2]
[3]
[4]
[5]
[6]
®
is a registered Danfoss trademark/Commercial Compressor
Function:
Logic rule 2 Use the result of logic rule 2.
Logic rule 3 Use the result of logic rule 3.
Digital input DI18 Use the result of digital input 18.
Digital input DI19 Use the result of digital input 19.
Digital input DI27 Use the result of digital input 27.
Digital input DI29 Use the result of digital input 29.
Digital input DI32 Use the result of digital input 32.
Digital input DI33 Use the result of digital input 33.
Start command A start command is issued.
Drive stopped A stop command (Jog, Stop, Qstop,
Coast) is issued – and not from the
SLC itself.
Reset Trip A reset is issued
Auto-reset Trip An Auto reset is performed.
Ok key The [OK] key is pressed.
Reset key The [Reset] key is pressed.
Left key
The [◄] key is pressed.
Right key
The [►] key is pressed.
▲
Up key
The [ ] key is pressed.
▼
Down key
The [ ] key is pressed.
Comparator 4 Use the result of comparator 4.
Comparator 5 Use the result of comparator 5.
Logic rule 4 Use the result of logic rule 4.
Logic rule 5 Use the result of logic rule 5.
RS Flipflop 0
RS Flipflop 1
RS Flipflop 2
RS Flipflop 3
RS Flipflop 4
RS Flipflop 5
Function:
False For descriptions [0]-[61], see
13-01 Start Event Start Event
True
Running
In range
On reference
Torque limit
Current limit
6 6
