How to Install
Power Bussmann
[kW] JFHR2
11 FWH-40
15 FWH-50
18 FWH-60
22 FWH-80
30 FWH-100
37 FWH-125
45 FWH-150
55 FWH-200
75 FWH-250
Table 3.14 380-500 V, Frame Sizes B and C
1)
Ferraz-Shawmut A50QS fuses may substitute for
A50P fuses.
Power Bussmann
[kW] Type RK1
11 KTS-R-35
15 KTS-R-45
18 KTS-R-50
22 KTS-R-60
30 KTS-R-80
37 KTS-R-100
45 KTS-R-125
55 KTS-R-150
75 KTS-R-175
Table 3.15 525-600 V, Frame Sizes B and C
Power SIBA
[kW] Type RK1
11 5014006-040
15 5014006-050
18 5014006-050
22 5014006-063
30 5014006-080
37 5014006-100
45 2028220-125
55 2028220-150
75 2028220-200
Table 3.16 525-600 V, Frame Sizes B and C
1) 170M fuses shown from Bussmann use the -/80
visual indicator. –TN/80 Type T, -/110 or TN/110
MG34M302 - VLT
Operating Instructions VLT
Recommended max. fuse
Ferraz- Shawmut
J
HSJ-40
HSJ-50
HSJ-60
HSJ-80
HSJ-100
HSJ-125
HSJ-150
HSJ-200
HSJ-250
Recommended max. fuse
Bussmann Bussmann
Type J Type T
JKS-35 JJS-35
JKS-45 JJS-45
JKS-50 JJS-50
JKS-60 JJS-60
JKS-80 JJS-80
JKS-100 JJS-100
JKS-125 JJS-125
JKS-150 JJS-150
JKS-175 JJS-175
Recommended max. fuse
Littel fuse
Type RK1
KLS-R-035
KLS-R-045
KLS-R-050
KLS-R-060
KLS-R-075
KLS-R-100
KLS-R-125
KLS-R-150
KLS-R-175
®
