Parameter Descriptions
13-10 Comparator Operand
Array [6]
Option:
[61] Below reference,
low
[62] Above ref, high
[65] Torque limit
[66] Current limit
6 6 [67] Out of current
range
[68] Below I low
[69] Above I high
[70] Out of speed
range
[71] Below speed low
[72] Above speed high The output speed is higher than the
[75] Out of feedb.
range
[76] Below feedb. low
[77] Above feedb. high The feedback is above the limit set in
[80] Thermal warning
[82] Mains out of
range
[85] Warning
[86] Alarm (trip)
[87] Alarm (trip lock)
[90] Bus OK
[91] Torque limit &
stop
[92] Brake fault (IGBT)
[93] Mech. brake
control
86
Operating Instructions VLT
Function:
The motor is running below the value
given in 4-54 Warning Reference Low
The motor is running above the value
given in 4-55 Warning Reference High
The torque limit, set in 4-16 Torque
Limit Motor Mode or 4-17 Torque Limit
Generator Mode, has been exceeded.
The motor current limit, set in
4-18 Current Limit, has been exceeded.
The motor current is outside the range
set in 4-18 Current Limit.
The motor current is lower than set in
4-50 Warning Current Low.
The motor current is higher than set
in 4-51 Warning Current High.
The speed is outside the range set in
4-52 Warning Speed Low and
4-53 Warning Speed High.
The output speed is lower than the
setting in 4-52 Warning Speed Low.
setting in 4-53 Warning Speed High.
The feedback is outside the range set
in 4-56 Warning Feedback Low and
4-57 Warning Feedback High.
The feedback is below the limit set in
4-56 Warning Feedback Low.
4-57 Warning Feedback High.
The thermal warning turns on when
the temperature exceeds the limit in
the motor, the frequency converter,
the brake resistor or thermistor.
The mains voltage is outside the
specified voltage range.
A warning is active.
A (trip) alarm is active.
A (Trip lock) alarm is active.
Active communication (no time-out)
via the serial communication port.
If the frequency converter has received
a stop signal and is at the torque limit,
the signal is logic "0".
The brake IGBT is short circuited.
The mechanical brake is active.
®
MG34M302 - VLT is a registered Danfoss trademark/Commercial Compressor
®
CDS302 and CDS303
13-10 Comparator Operand
Array [6]
Option: Function:
[94] Safe stop active
[100] Comparator 0 The result of comparator 0.
[101] Comparator 1 The result of comparator 1.
[102] Comparator 2 The result of comparator 2.
[103] Comparator 3 The result of comparator 3.
[104] Comparator 4 The result of comparator 4.
[105] Comparator 5 The result of comparator 5.
[110] Logic rule 0 The result of Logic rule 0.
[111] Logic rule 1 The result of Logic rule 1.
[112] Logic rule 2 The result of Logic rule 2.
[113] Logic rule 3 The result of Logic rule 3.
[114] Logic rule 4 The result of Logic rule 4.
[115] Logic rule 5 The result of Logic rule 5.
[120] SL Time-out 0 The result of SLC timer 0.
[121] SL Time-out 1 The result of SLC timer 1.
[122] SL Time-out 2 The result of SLC timer 2.
[123] SL Time-out 3 The result of SLC timer 3.
[124] SL Time-out 4 The result of SLC timer 4.
[125] SL Time-out 5 The result of SLC timer 5.
[126] SL Time-out 6 The result of SLC timer 6.
[127] SL Time-out 7 The result of SLC timer 7.
[130] Digital input DI18 Digital input 18. High = True.
[131] Digital input DI19 Digital input 19. High = True.
[132] Digital input DI27 Digital input 27. High = True.
[133] Digital input DI29 Digital input 29. High = True.
[134] Digital input DI32 Digital input 32. High = True.
[135] Digital input DI33 Digital input 33. High = True.
[150] SL digital output Use the result of the SLC output A.
A
[151] SL digital output B Use the result of the SLC output B.
[152] SL digital output Use the result of the SLC output C.
C
[153] SL digital output Use the result of the SLC output D.
D
[154] SL digital output E Use the result of the SLC output E.
[155] SL digital output F Use the result of the SLC output F.
[160] Relay 1 Relay 1 is active
[161] Relay 2 Relay 2 is active
[180] Local ref. active High when 3-13 Reference Site = [2]
Local or when 3-13 Reference Site is [0]
