Parameter Descriptions
6.16.4 3-** Reference/Ramps
Par. Parameter description
No. #
3-0* Reference Limits
3-02 Minimum Reference
3-03 Maximum Reference
3-04 Reference Function
3-1* References
3-10 Preset Reference
3-11 Jog Speed [Hz]
3-13 Reference Site
3-14 Preset Relative Reference
3-15 Reference 1 Source
3-16 Reference 2 Source
3-17 Reference 3 Source
3-19 Jog Speed [RPM]
3-4* Ramp 1
3-41 Ramp 1 Ramp Up Time
3-42 Ramp 1 Ramp Down Time
3-5* Ramp 2
3-51 Ramp 2 Ramp Up Time
3-52 Ramp 2 Ramp Down Time
3-8* Other Ramps
3-80 Jog Ramp Time
3-81 Quick Stop Ramp Time
3-82 Starting Ramp Up Time
3-9* Digital Pot.Meter
3-90 Step Size
3-91 Ramp Time
3-92 Power Restore
3-93 Maximum Limit
3-94 Minimum Limit
3-95 Ramp Delay
Table 6.20
MG34M302 - VLT
®
Operating Instructions VLT
Default value
ExpressionLimit
ExpressionLimit
[0] Sum
0 %
ExpressionLimit
[0] Linked to Hand / Auto
0 %
[1] Analog Input 53
[20] Digital pot.meter
[0] No function
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
0.10 %
1 s
[0] Off
100 %
0 %
1 N/A
®
is a registered Danfoss trademark/Commercial Compressor
CDS302 and CDS303
4-set-up Change
during
operation
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
Conver- Type
sion index
-3 Int32
-3 Int32
- Uint8
-2 Int16
-1 Uint16
- Uint8
-2 Int32
6
- Uint8
- Uint8
- Uint8
67 Uint16
-2 Uint32
-2 Uint32
-2 Uint32
-2 Uint32
-2 Uint32
-2 Uint32
-2 Uint32
-2 Uint16
-2 Uint32
- Uint8
0 Int16
0 Int16
-3 TimD
