Parameter Descriptions
6.16.8 7-** Controllers
Par. Parameter description
No. #
7-0* Speed PID Ctrl.
7-00 Speed PID Feedback Source
7-02 Speed PID Proportional Gain
7-03 Speed PID Integral Time
7-04 Speed PID Differentiation Time
7-05 Speed PID Diff. Gain Limit
7-06 Speed PID Lowpass Filter Time
7-07 Speed PID Feedback Gear Ratio
7-08 Speed PID Feed Forward Factor
7-09 Speed PID Error Correction w/ Ramp
7-1* Torque PI Ctrl.
7-12 Torque PI Proportional Gain
7-13 Torque PI Integration Time
7-2* Process Ctrl. Feedb
7-20 Process CL Feedback 1 Resource
7-22 Process CL Feedback 2 Resource
7-3* Process PID Ctrl.
7-30 Process PID Normal/ Inverse Control
7-31 Process PID Anti Windup
7-32 Process PID Start Speed
7-33 Process PID Proportional Gain
7-34 Process PID Integral Time
7-35 Process PID Differentiation Time
7-36 Process PID Diff. Gain Limit
7-38 Process PID Feed Forward Factor
7-39 On Reference Bandwidth
Table 6.24
MG34M302 - VLT
®
Operating Instructions VLT
Default value
null
App.Dependent
App.Dependent
App.Dependent
5.0 N/A
App.Dependent
1.0000 N/A
0%
300RPM
100%
0.020 s
[0] No function
[0] No function
[0] Normal
[1] On
0 RPM
0.01 N/A
10000.00 s
0.00 s
5.0 N/A
0%
5%
®
is a registered Danfoss trademark/Commercial Compressor
CDS302 and CDS303
4-set-up Change
during
operation
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
Conver- Type
sion index
- Uint8
-3 Uint16
-4 Uint32
-4 Uint16
-1 Uint16
-4 Uint16
-4 Uint32
0 Uint16
6
67 Uint32
0 Uint16
-3 Uint16
- Uint8
- Uint8
- Uint8
- Uint8
67 Uint16
-2 Uint16
-2 Uint32
-2 Uint16
-1 Uint16
0 Uint16
0 Uint8
