Parameter Descriptions

6.5 Parameters: 4-** Limits/Warnings

6.5.1 4-1* Motor Limits
Define torque, current and speed limits for the motor, and
the reaction of the frequency converter when the limits are
exceeded.
A limit may generate a message on the display. A warning
will always generate a message on the display or on the
fieldbus. A monitoring function may initiate a warning or a
trip, upon which the frequency converter will stop and
generate an alarm message.
4-20 Torque Limit Factor Source
Option: Function:
Select an analog input for scaling the
settings in 4-16 Torque Limit Motor
Mode and 4-17 Torque Limit Generator
Mode from 0% to 100% (or inverse).
The signal levels corresponding to
0% and 100% are defined in the
analog input scaling, e.g. parameter
group 6-1*. This parameter is only
active when 1-00 Configuration Mode
is in Speed Open Loop or Speed Closed
Loop.
[0] No function
*
[2] Analog in 53
[4] Analog in 53 inv
[6] Analog in 54
[8] Analog in 54 inv
[10] Analog in X30-11
[12] Analog in X30-11
inv
[14] Analog in X30-12
[16] Analog in X30-12
inv
4-21 Speed Limit Factor SourceOption
Option: Function:
Select an analog input for scaling
the settings in 4-19 Max Output
Frequency from 0% to 100% (or vice
versa). The signal levels
corresponding to 0% and 100% are
defined in the analog input scaling,
e.g. parameter group 6-1*. This
parameter is only active when
1-00 Configuration Mode is in Torque
Mode.
[0] No function
*
[2] Analog input 53
[4] Analog input 53 inv
[6] Analog input 54
[8] Analog input 54 inv
[10] Analog input X30-11
MG34M302 - VLT
®
Operating Instructions VLT CDS302 and CDS303
4-21 Speed Limit Factor SourceOption
Option:
[12] Analog input X30-11
inv
[14] Analog input X30-12
[16] Analog input X30-12
inv
6.5.2 4-5* Adjustable Warnings
Use these parameters to adjust warning limits for current,
speed, reference and feedback. Warnings that are shown
on the display can be programmed as an output or sent
via serial bus.
4-50 Warning Current Low
Range:
0 A
*
4-51 A]
4-51 Warning Current High
Range:
Size
related
4-52 Warning Speed Low
Range:
Size
related
4-53 Warning Speed High
Range:
Size related
4-54 Warning Reference Low
Range:
-999999.999
®
is a registered Danfoss trademark/Commercial Compressor
Function:
Function:
[ 0 - par. Enter the I value. When the motor current
LOW
falls below this limit, the display reads Current
Low. The signal outputs can be programmed
to produce a status signal on terminal 27 or
29 and on relay output 01 or 02. Refer to .
Function:
[ par. 4-50 Enter the I
HIGH
- par. 16-37 current exceeds this limit, the display
*
A] reads Current High. The signal outputs
can be programmed to produce a
status signal on terminal 27 or 29 and
on relay output 01 or 02. Refer to .
Function:
[ 0 - par. Enter the n
LOW
4-53 RPM] speed exceeds this limit, the display
*
reads Speed Low. The signal outputs
can be programmed to produce a
status signal on terminal 27 or 29 and
on relay output 01 or 02.
[ par. 4-52 - par. 4-13 RPM]
*
Function:
[ -999999.999 - Enter the lower reference limit.
*
par. 4-55 ] When the actual reference falls
below this limit, the display
indicates Ref
outputs can be programmed to
produce a status signal on
terminal 27 or 29 and on relay
output 01 or 02.
6
value. When the motor
value. When the motor
Function:
. The signal
LOW
