Parameter Descriptions
6.16.13 25-** Cascade Pack Controller
Par. Parameter description
No. #
25-0* System Settings
25-00 Pack Controller
25-04 Compressor Cycling
25-06 Number of Compressors
25-2* Zone Settings
25-20 Neutral Zone [unit]
25-21 + Zone [unit]
25-22 - Zone [unit]
25-23 Fixed Speed neutral Zone [unit]
6 6
25-24 + Zone Delay
25-25 - Zone Delay
25-26 ++ Zone Delay
25-27 -- Zone Delay
25-3* Staging Functions
25-30 Destage At No-Flow
25-31 Stage Function
25-32 Stage Function Time
25-33 Destage Function
25-34 Destage Function Time
25-4* Staging Settings
25-42 Staging Threshold
25-43 Destaging Threshold
25-44 Staging Speed [RPM]
25-45 Staging Speed [Hz]
25-46 Destaging Speed [RPM]
25-47 Destaging Speed [Hz]
25-8* Status
25-80 Pack Status
25-81 Compressor Status
25-82 Lead Compressor
25-83 Relay Status
25-84 Compressor ON Time
25-85 Relay ON Time
25-86 Reset Relay Counters
25-87 Inverse Interlock
25-88 Pack capacity [%]
25-9* Service
25-90 Compressor Interlock
25-91 Manual Alternation
Table 6.29
