Parameter Descriptions
6.16.5 4-** Limits / Warnings
Par. Parameter description
No. #
4-1* Motor Limits
4-10 Motor Speed Direction
4-11 Motor Speed Low Limit [RPM]
4-12 Motor Speed Low Limit [Hz]
4-13 Motor Speed High Limit [RPM]
4-14 Motor Speed High Limit [Hz]
4-16 Torque Limit Motor Mode
4-17 Torque Limit Generator Mode
4-18 Current Limit
6 6
4-19 Max Output Frequency
4-5* Adj. Warnings
4-50 Warning Current Low
4-51 Warning Current High
4-52 Warning Speed Low
4-53 Warning Speed High
4-54 Warning Reference Low
4-55 Warning Reference High
4-56 Warning Feedback Low
4-57 Warning Feedback High
4-58 Missing Motor Phase Function
4-6* Speed Bypass
4-60 Bypass Speed From [RPM]
4-61 Bypass Speed From [Hz]
4-62 Bypass Speed To [RPM]
4-63 Bypass Speed To [Hz]
4-64 Semi-Auto Bypass Set-up
Table 6.21
128
Operating Instructions VLT
Default value
[0] Clockwise
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ImaxVLT (P1637)
outputSpeedHighLimit (P413)
-999999 N/A
999999 N/A
-999999 ReferenceFeed-
999999 ReferenceFeed-
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
ExpressionLimit
®
MG34M302 - VLT is a registered Danfoss trademark/Commercial Compressor
®
CDS302 and CDS303
4-set-up
All set-ups
All set-ups
All set-ups
All set-ups
All set-ups
110 % All set-ups
100 % All set-ups
All set-ups
All set-ups
0 A All set-ups
All set-ups
0 RPM All set-ups
All set-ups
All set-ups
All set-ups
backUnit All set-ups
backUnit All set-ups
All set-ups
All set-ups
All set-ups
All set-ups
All set-ups
[0] Off All set-ups
Change Conver- Type
during sion index
operation
FALSE - Uint8
TRUE 67 Uint16
TRUE -1 Uint16
TRUE 67 Uint16
TRUE -1 Uint16
TRUE -1 Uint16
TRUE -1 Uint16
TRUE -1 Uint32
FALSE -1 Uint16
TRUE -2 Uint32
TRUE -2 Uint32
TRUE 67 Uint16
TRUE 67 Uint16
TRUE -3 Int32
TRUE -3 Int32
TRUE -3 Int32
TRUE -3 Int32
TRUE - Uint8
TRUE 67 Uint16
TRUE -1 Uint16
TRUE 67 Uint16
TRUE -1 Uint16
FALSE - Uint8
