ompar ison, 7 Bi t/ 8 Bi t
8 B i t
IND
NEL
HTS
VTS
PLD
PLU
DCS
PU1
CSI
ST
OSC

8-bit Control Codes

7265 Programmer's Manual
Copyright © 2004 TallyGenicom
Hex Description
84 Index
85 Next Line
88 Set Horizontal Tab
8A Set Vertical Tab
8B Partial Line Down
8C Partial Line Up
RI 8D Reverse Index
90 Device Control String
91 Private Use 1
9B Control String Introducer
9C String Terminator
9D Straps and Options Introducer
ANSI assigns control functions to characters 80 hex through 9F hex and calls these characters
C1 codes. You can set the printer to either interpret 80 hex - 9F hex as control codes or not. The
ISU default status of this option is disabled.
You can toggle the status of the 8-bit control code enable from the Emulations Options Menu or
with escape sequences. The pertinent escape sequences are the ANSI private use sequences
described on page 12. In 8-bit mode, all of the lower contro l codes and ESC sequences remain
active. For example, you can use either PLD or ESC K for subscript printing. In 7-bit mode, only
ESC K is available.
If 8-bit control code interpretation is disabled, then the printer processes characters 80 hex
through 9F hex according to IBM PC character sets 1 or 2, depending on which is currently
selected. The default is character set 1. You can toggle the character set selection from the
Emulation Options Menu.
If 8-bit control code interpretation is disabled and character set 1 is active, then the printer strips
the most significant bit of characters 80 hex through 9F hex. For example, if you send 8A hex
when 8-bit control code interpretation is disabled and character set 1 is active, then the printer
treats 8A hex as 0A hex and performs a line feed.
7 Bit Hex
ESC D 1B 44
ESC E 1B 45
ESC H 1B 48
ESC J 1B 4A
ESC K 1B 4B
ESC L 1B 4C
ESC M 1B 4D
ESC P 1B 50
ESC Q 1B 51
ESC [ 1B 5B
ESC \ 1B 5C
ESC ] 1B 5D
