Barcode Printing

Barcode
Before the data, which contains the barcode information, are transmitted to the printer,
the barcode header must be sent. Otherwise the standard parameter values are used
Header
(see section "Header Format"). In the header, the printing parameters, the barcode size
and the barcode type are defined. This header only needs to be transferred once, unless
settings are to be changed or the printer has been turned off.
Format: SUB [F] a [n] [;xyz] EM

Header Format

[ ]
x, y
Meaning of the characters:
SUB (hex.1A, dec.26)
F
a
n
;
x
y
z
EM
For encoding ASCII values to decimal or hexadecimal values refer to the appendix,
"Character Sets".
8
Barcode Printing
Specification is optional
unregarded at EAN/UPC-Barcode!
For Code 128 and EAN 128 (Type S+T) only the X parameter is valid. This is
automatically used for the Y parameter. The Z parameter is not evaluated.
ASCII a = "A"..."S"
ASCII n = "0"..."90"
ASCII
ASCII x = "0"..."3"
ASCII y = "0"..."3"
ASCII z = "0"..."3"
(hex.19, dec.25)
Start header
Print feature (see section "Barcode Print Feature F"
to select the F codes, page 10)
Barcode Types (see section "Barcode Types")
Barcode height in n/6 inch.
At n="0" the barcode height equals to 1/12 inch.
Separation character
Width of the narrow bar (see section "Barcode width")
Width of the narrow space (see section "Barcode width")
Ratio of wide to narrow (see section "Barcode width")
End of header
