TallyGenicom Matrix Printer Programmer's Manual page 14

Commands Descript i on
DEL DELETE
DEL is a printable character, or is a valid graphics data byte if received
in dot g r aphics mode.
Dec 127
ESC [(p1); SELECT EMULATION
(p2)<SP>~
If p2 is 0, which is the default, then the current settings in the printer remain in effect
through the emulation change to the extent that selected features are supported in
the target emulation. This affects such things as, font selection, character pitch,
margins, tabs, and so forth. If p2 is 1, then the status of such parameters reverts to
defaults dependent on the selected emulation.
p1
0
1
2-21
22
p2
0-1
Example: Select Epson emulation with full reset:
Dec 27 91 50 50 59 49 32 126
ESC [(p1)p SELECT PAPER PATH
p1
08
10
12
Forms in the current path should be torn off before changing paper paths. If
you send a command to change paper paths and there is more paper
downstream of the print head than 1/2 times the current form length or six
inches, whichever is greater, then the printer returns paper to the position that
was current before the command was received, and a fault condition is set.
If you send a command to change paper paths and the target path is the
current path, then the printer executes a form feed. If you load tractor 2
when tractor 2 is not installed, the command will be ignored.
Example: Unload tractor 1 and load tractor 2:
Dec 27 91 49 48 112
7265 Programmer's Manual
Copyright © 2004 TallyGenicom
Hex 7F
selects
GENICOM ANSI
Tally ANSI
Reserved
Epson FX286e
selects
full reset
selects
unload current path
unload current path and load tractor 2
unload current path and load tractor 1
Hex 1B 5B 32 32 3B 31 20 7E
Hex 1B 5B 31 30 70
10
Chapter 2 ANSI
