Secured/Unsecured Mode

Unsecured mode
Secured mode
Data Structure ASCII
hex.
dec.
ASCII
hex.
dec.

Description

In secured mode, the amount of space the barcode or LCP character requires is "secu-
red". In each line, additional barcode and normal characters can be printed.
These additional characters are printed in the current line and in the following lines wi-
thout influencing the barcode or LCP character. As a result normal characters can be prin-
ted to the right or left of the barcode or LCP character in each line.
In order to guarantee successful barcode and LCP character printing, it is important to in-
sert the correct paper feed commands, so that paper feed is ensured to the end of the
barcode and LCP height.
In unsecured mode, the paper feed necessary for barcode and LCP printing is automatic
and it is not possible to print more than one line with normal characters in the barcode
and LCP line.
All characters in the mixed line are printed, so that the bottom edges are aligned in a
straight line.
6
Secured/Unsecured Mode
ESC "P" "S" "C" "0"
1B 50 53 43 30
27 80 83 67 48
ESC "P" "S" "C" "1"
1B 50 53 43 31
27 80 83 67 49
ESC PSC0 ESC \
ESC PSC1 ESC \
ESC "\" Unsecured mode
1B 5C
27 92
ESC "\" Secured mode
1B 5C
27 92
