Sheet Feeder - TallyGenicom Matrix Printer Programmer's Manual

Sheet Feeder

Data Structure
ASCII
hex.
dec.
ASCII
hex.
dec.
ASCII
hex.
dec.
ASCII
hex.
dec.
ASCII
hex.
dec.
Description This code sequence should only be used when the sheet feeder is mounted and se-
lected. Parameters for sheet feeder operation set via the control panel are deactivated.
When sheet feeder operation is activated, the paper is fed automatically by a received
code FF. If the last print position is outside the defined print area, the paper will additio-
nally be fed by codes LF, VT, or ESC J.
The form length must be defined in accordance with the paper format used.
108
Miscellaneous
ESC EM "0" deactivate sheet feeder operation
1B 19 30
27 25 48
ESC EM "1" select magazine 1 (front)
1B 19 31
27 25 49
ESC EM "2" select magazine 2 (rear)
1B 19 32
27 25 50
ESC EM "4" activate sheet feeder operation
1B 19 34
27 25 51
ESC EM "R" eject paper
1B 19 52
27 25 82
ESC EM
