Activation of Character Sets

Data Structure ASCII
hex.
dec.
ASCII
hex.
dec.
ASCII
hex.
dec.
Description
These sequences activate various character sets (also see Invocation of Character Set
G0 - G3, page 83). 4 registers - from G0 until G3 - are supported. Into each of these
registers a graphic character set by a designation sequence can be placed.
SI
0F
15
SO
0E
14
ESC n
1B n
27 n
Activation of G0 for codes 21 - 7E
Activation of G1 for codes 21 - 7E
For n the following parameters are available:
n hex. dec.
n 6E 110
o 6F 111
| 7C 124
} 7D 125
~ 7E 126
ZG locking shift LS0
ZG locking shift LS1
ZG locking shift LS2, LS3, LS1R, LS2R, LS3R
locking shift (LS)
[B] LS2: Activation of G2 for codes 21 - 7E
[B] LS3: Activation of G3 for codes 21 - 7E
[B] LS3R: Activation of G3 for codes A1 - FE
[B] LS2R: Activation of G2 for codes A1 - FE
[A] LS1R: Activation of G1 for codes A1 - FE
SI
SO
ESC ...
81
