Forms Setup

Command Description
ESC [(p1); FORMS SETUP
(p2);(p3);(p4)
Sets top of form and sets form length, as well as top and bottom margins, in decipoints.
;(p5)r
Parameter
p1
p2
p3
line and the end of form.
p4
p5
Any parameter not specified is assigned its default value. Maximum form length is
15840 decipoints (22 inches).
Default Values
p1
p2
p3
p4
p5
Example:
Set 8-inch form length, one-inch top margin, one-inch bottom margin
Dec 27 91 53 55 54 48 59 55 50 48 59 55 50 48 114
Hex 1B 5B 35 37 36 30 3B 37 32 30 3B 37 32 30 72
Note: Before you send this command, verify that the top print reference is zero in the
target paper path. One way to do this is to park and then load paper in the target path.
The top edge of the paper should line up with the top of the print head. If not, then set
the top print reference to zero from the menu and save the change to the format
associated with the target paper path. You must once again park and load paper in the
target path in order for the new print reference to take effect.
Next, send a command to set the vertical position-absolute to zero. If you do not do
this, then the printer establishes top-of-form at the current top margin, and form
registration is lost.
7265 Programmer's Manual
Copyright © 2004 TallyGenicom
is form length
is the top margin,
sets the length of white space between the baseline of the last allowed
is the top print reference, and
is the left print reference
7920 decipoints
0 decipoints
0 decipoints
0 decipoints
0 decipoints
720ths
11-inch form
0-inch top margin
0-inch bottom margin
0-inch top print reference
0-inch left print reference
,
20
Chapter 2 ANSI
