Double Strike - TallyGenicom Matrix Printer Programmer's Manual

Double Strike ON
Double Strike OFF
Data Structure ASCII
hex.
dec.
ASCII
hex.
dec.
–
Description This code sequence switches the printer to double strike mode. In double strike mode
characters are printed in two printing passes at the same horizontal position; thus print
appears thicker and fuller. Print speed is reduced since the characters are printed
twice.
Double strike mode can be used in combination with emphasized mode (ESC E).
Double strike mode is reset when the printer receives the code sequence ESC H.
—
This code sequence resets the double strike mode set by ESC G or ESC !.
This code sequence is ignored when the printer is not in double strike mode.
Example
10 REM
20 LPRINT CHR$(27);"H";
30 LPRINT "this is normal printing ";
40 LPRINT CHR$(27);"G";
50 LPRINT "and this is double strike printing"
60 END
ESC "G" double strike ON
1B 47
27 71
ESC "H" double strike OFF
1B 48
27 72

double strike

–
—
Character Styling
ESC G
ESC H
31
