Graphics

Graphics 60 dpi

Graphics 120 dpi

High Speed Graphics 120 dpi

Graphics 240 dpi

Graphic Modes

Data Structure ASCII
hex.
dec.
ASCII
hex.
dec.
ASCII
hex.
dec.
ASCII
hex.
dec.
ASCII
hex.
dec.
Description Data following the graphics ESC-sequence is printed out as a dot pattern. The number of
bytes of the graphics string is defined by n
and the available parameter values m for the ESC * code sequences on the following
page.
ESC "K" <n > <n >
1 2
1B 4B <n > <n >
1 2
27 75 <n > <n >
1 2
ESC "L" <n > <n >
1 2
1B 4C <n > <n >
1 2
27 76 <n > <n >
1 2
ESC "Y" <n > <n >
1 2
1B 59 <n > <n >
1 2
27 89 <n > <n >
1 2
ESC "Z" <n > <n >
1 2
1B 5A <n > <n >
1 2
27 90 <n > <n >
1 2
ESC " * " <0> <n > <n
1
1B 2A 00 <n > <n
1
27 42 0 <n > <n
1
graphics 60 dpi
graphics 120 dpi
high speed graphics 120 dpi
graphics 240 dpi
> graphic modes
2
>
2
>
2
and n . You will find a list of all sequences
1 2
ESC K
ESC L
ESC Y
ESC Z
ESC *
63
Graphics
