Code 11 (Style 7)

1 Bars per character: 3 dark bars and 2 light bars
2 Character set: 0 through 9 and the dash character
3 Start/Stop characters: Yes
4 Center character code: None
5 NULL character: Yes
6 Intercharacter gap: None
7 Characters per symbol: Variable
8 Check digit: If needed, it must be generated by the data source
9 Delimiters: Space, comma, horizontal tab, hp_relative
10 HR characters: Currently selected font, special HR font, special OCR-A/OCR-B
font (120 DPI only)
11 CPI at default element widths: 6.00
12 Combined start-stop character length: 0.306"
