Duplexer Setup Guide

The optional duplexer enables printing on both sides of a sheet of paper.

Unpack the duplexer from its shipping container.

WARNING: To prevent the danger of electric shock, before installing any options be sure to

turn the power switch of the printer to the off [O] position and disconnect the power cord

from the wall outlet.

Ensure that the printer power switch is set to the OFF [ O ] position.

Dec 98

Duplexer Setup Guide 1

Publication No. GEK-89569

Page 1 Unpack the duplexer from its shipping container. WARNING: To prevent the danger of electric shock, before installing any options be sure to turn the power switch of the printer to the off [O] position and disconnect the power cord from the wall outlet.
Page 2 Disconnect the power cord from the wall outlet. NOTE: If an optional face-up tray is installed on your printer, complete the following two steps to remove it, otherwise proceed directly to Step 6 below. Lift to remove the face-up tray.
Page 3 Firmly insert the stopper on the right side of the duplexer into the printer. Secure the duplexer by hooking the safety wire of the unit to the printer as indicated. Dec 98 Duplexer Setup Guide 3...
Page 4 Duplexer Setup Guide Plug the cable of the duplexer into the connector on the printer. Close the duplexer. Connect the power cord to the wall outlet. Publication No. GEK-89569 Dec 98...
Page 5 Duplexer Setup Guide 5 Turn the printer power switch to the ON [ I ] position. The installation of the duplexer option is now complete. Dec 98 Publication No. GEK-89569...
Page 6 Duplexer Setup Guide Publication No. GEK-89569 Dec 98...
