Msi (Style19) - TallyGenicom Matrix Printer Programmer's Manual

MSI (Style19)

1 Bars per character: 4 dark bars and 4 light bars
2 Character set: 0 through 9
3 Start characters: 1 dark bar and 1 light bar Stop characters: 2 dark bars and 1
light bar
4 Center character code: None
5 NULL character: Yes
6 Intercharacter gap: None
7 Characters per symbol: Variable
8 Check digit: The check digit
can be supplied by the data source
9 Delimiters: Space, comma, horizontal tab, hp_relative
10 HR characters: Currently selected font, special HR font, special OCR-A/OCR-B
font (120 DPI only)
11 CPI at default element widths: 3.8
12 Combined start-stop character length: 0.153"
7265 Programmer's Manual
Copyright © 2004 TallyGenicom
55
Chapter 3 ANSI Bar Codes
