Size of Character Set (1 Character Set)

Size of Character Set (2 Character Sets)

Data Structure ASCII
hex.
dec.
ASCII
hex.
dec.
Description In an 8 bit environment, the MTPL standard allows the use of 2 character sets at the same
time. In this case each character set contains 94 and 96 characters respectively and can
be allocated to the lower or upper half of the code table.
(Example: The control code SI activates G0 in the code range 21 - 7E and therefore loads
G0 in the lower half of the code table - see also function "Activation of Character Sets" on
page 79).
This function can be used, for example, to activate a table of PC code page tables.
If the setting "Character 8/0 to 9/F printable" is active (default setting) ESC [ ? 53 l has
STOP
to be sent instead of CSI ? 53 l, because the CSI character is not accepted as control
code.
88
Miscellaneous
CSI "?" "5"
9B 3F 35
155 63 53
CSI "?" "5"
9B 3F 35
155 63 53
This function causes a character set with 256 characters to be loaded by the control
codes SO, SI, ESC n or ESC o. Thus, the activation of character sets with the using
of the codes ESC | , ESC } and ESC ~ becomes ineffective.
With this sequence, the function set by CSI ? 50 h is turned off. Thus, the activation of
character sets with 94 and 96 characters becomes effective again.
"0" "h" [A] loading a character set
30 68 with 256 characters
48 104
l
"0" " " [A] loading 2 character sets
30 69 with 94 characters each
48 105
CSI ? 50 h
l
CSI ? 50
