Setting Bar Code Parameters

The ANSI control sequence that sets bar code parameters has the format:
Command Description
ESC Set Up Bar Code Parameters
[p1;p2;p3;p4;p
Determines bar code parameters to be used when bar code mode is enabled.
5;p6;p7;p8;p9;
See following sections.
p10;p11;p12;p
Dec 27 91 (p1) 59 (p2) 59...(p13)125
13}
Hex 1B 5B (p1) 3B (p2) 3B...(p13) 7D
Bar Code Height
Parameter p2
Human Readable
Line Parameter p3
7265 Programmer's Manual
Copyright © 2004 TallyGenicom
Wide Bar Width
Parameter p5
0123456789 0123456789 0123456789 0123456789
0123456789
Narrow Space
Width Parameter p6

Figure 3-1 Parts of a Bar Code

Narrow Bar Width
Parameter p4
Wide Space Width
Parameter p7
Chapter 3 ANSI Bar Codes
