gefran ADV200 Functions Description And Parameters List page 54

Menu PAR Description
11.17 1042 FR forward src
Selection of the origin (source) for the FR forwardstart signal. With this command the motor starts to rotate
(with the Enable command enabled). The terminal to be associated with this function can be selected from the
"L_DIGSEL2" selection list.
Menu PAR Description
11.18 1044 FR reverse src
Selection of the origin (source) for the FR reverse signal. With this command the motor reverses the direc-
tion of rotation (with the Enable command enabled). The terminal to be associated with this function can be
selected from the "L_DIGSEL2" selection list.
Menu PAR Description
11.19 1046 FR *stop src
Selection of the origin (source) for the FR stop signal. The terminal to be associated with this function can be
selected from the "L_DIGSEL2" selection list.
Menu PAR Description
11.20 1048 FR start mon
The status of the Start output of the Forward Reverse Control (FRC) block is displayed.
0 Stop
1 Start
Menu PAR Description
11.21 1050 FR reverse mon
The status of the Reverse output of the Forward Reverse Control (FRC) block is displayed.
0 No Reverse
1 Reverse
Menu PAR Description
11.22 1052 FR cdm mon
The status of the commands of the Forward Reverse Control (FRC) block are displayed.
FR *stop src
0
0
0
0
1
1
1
1
Menu PAR Description
11.23 1032 Drv Interlock src
This parameter is used to select the origin (source) of the Drv Interlock signal.
The signal to be associated with this function can be selected from the "L_DIGSEL2" selection list.
0 Drive interlock active (Drive disabled)
1 Drive interlock not active (Drive can be enabled)
54
UM Type FB BIT
LINK 16
UM Type FB BIT
LINK 16
UM Type FB BIT
LINK 16
UM Type FB BIT
BIT 16
UM Type FB BIT
BIT 16
UM Type FB BIT
UINT16
FR reverse src FR forward src
0
0
1
1
0
0
1
1
UM Type FB BIT
LINK 16
Def Min
1112 0
Def Min
1114 0
Def Min
6000 0
Def Min
0 0
Def Min
0 0
Def Min
0 0
FR cdm mon
0 0
1 1
0 2
1 3
0 4
1 5
0 6
1 7
Def Min
6002 0
ADV200 • Functions description and parameters list
Max Acc Mod
16384 ERW FVS
Max Acc Mod
16384 ERW FVS
Max Acc Mod
16384 ERW FVS
Max Acc Mod
1 ER FVS
Max Acc Mod
1 ER FVS
Max Acc Mod
0 ER FVS
Max Acc Mod
16384 ERW FVS
